D52 - Neodymium Disc Magnet - 5/16" Dia x 1/8" Thi

• Dimensions: 5/16" dia. x 1/8" thick
• Tolerances: ±0.004" x ±0.004"
• Material: NdFeB, Grade N42
• Plating/Coating: Ni-Cu-Ni (Nickel)
• Magnetization Direction: Axial (Poles on Flat Ends)
• Weight: 0.0416 oz. (1.18 g)
• Pull Force, Case 1: 3.36 lbs
• Pull Force, Case 2: 6.40 lbs
• Surface Field: 4123 Gauss
• Max Operating Temp: 176ºF (80ºC)
• Brmax: 13,200 Gauss
• BHmax: 42 MGOe

This particular size may be modest, yet is very powerful for its size. Very versatile!

This size is also available in grade N52 as part number D52-N52.
