DC6TP-N52 - Neodymium Rubber Coated Disc Magnet - 3/4" Dia x 3/8 " Thi

• Dimensions: 3/4" dia. x 3/8" thick
• Tolerances: ±0.004" x ±0.004"
• Material: NdFeB, Grade N52
• Plating/Coating: Thermoplastic
• Magnetization Direction: Axial (Poles on Flat Ends)
• Weight: 0.562 oz. (15.9 g)
• Pull Force, Case 1: 13.12 lbs
• Pull Force, Case 2: 21.53 lbs
• Surface Field: 4750 Gauss
• Max Operating Temp: 176ºF (80ºC)
• Brmax: 14,800 Gauss
• BHmax: 52 MGOe

These great magnets are coated with a durable layer of protective thermoplastic. The 3/4" x 3/8" dimensions are the finished dimensions of the thermoplastic. These discs can be slammed together many times without damage. They won't mark or scratch surfaces they come in contact with.

The thermoplastic is very water resistant. The rubber-like coating also helps to limit slipping on smooth surfaces as we describe in our Leverage & Friction article.
