DH1H2 - Neodymium Cylinder Magnet - 1/10" Dia x 2/10" Thi

• Dimensions: 1/10" dia. x 2/10" thick
• Tolerances: ±0.004" x ±0.004"
• Material: NdFeB, Grade N42
• Plating/Coating: Ni-Cu-Ni (Nickel)
• Magnetization Direction: Axial (Poles on Flat Ends)
• Weight: 0.00681 oz. (0.193 g)
• Pull Force, Case 1: 0.53 lbs
• Pull Force, Case 2: 0.58 lbs
• Surface Field: 6403 Gauss
• Max Operating Temp: 176ºF (80ºC)
• Brmax: 13,200 Gauss
• BHmax: 42 MGOe

The DH1H2 is one of our many new additions featuring a true 0.100" (+/-0.004") diameter. These little magnets are in high demand since they are perfectly sized for use in today's ever-shrinking electronics, sensors and various medical devices. It's doubtful you'll find these unique sizes anywhere but K&J Magnetics!
