DX02-N52 - Neodymium Disc Magnet - 1" Dia x 1/8" Thi

• Dimensions: 1" dia. x 1/8" thick
• Tolerances: ±0.004" x ±0.004"
• Material: NdFeB, Grade N52
• Plating/Coating: Ni-Cu-Ni (Nickel)
• Magnetization Direction: Axial (Poles on Flat Ends)
• Weight: 0.426 oz. (12.1 g)
• Pull Force, Case 1: 15.60 lbs
• Pull Force, Case 2: 70.57 lbs
• Surface Field: 1803 Gauss
• Max Operating Temp: 176ºF (80ºC)
• Brmax: 14,800 Gauss
• BHmax: 52 MGOe

The DX02-N52 is a strong grade N52 NdFeB disc in the very popular 1" diameter. The nice thin shape allows the DX02-N52 to be used inconspicuously for a wide array of applications requiring strong holding force.

This size is also available in grade N42 as part number DX02 and in grade N52 with Gold plating as part number DX02G-N52.
