D8X8 - Neodymium Cylinder Magnet

d8x8-neodymium-cylinder-magnet--thumbnail-2

$8.66

Buy more, Save more!

Quantity based discounts

Price ea.	Qty	Discount
$8.66	1
$8.47	2-4	2%
$8.28	5-9	4%
$8.08	10-24	7%
$7.89	25-49	9%
$7.70	50-99	11%
$7.51	100-249	13%
$7.31	250-499	16%
$7.12	500-999	18%
$6.93	1000-2499	20%
Email us for even bigger discounts on higher order quantities

Description
Technical
Downloads

Dimensions: 1/2" dia. x 1 1/2" thick
Tolerances: ±0.004" x ±0.004"
Material: NdFeB, Grade N42
Plating/Coating: Ni-Cu-Ni (Nickel)
Magnetization Direction: Axial (Poles on Flat Ends)
Weight: 1.28 oz. (36.2 g)
Pull Force, Case 1: 16.85 lbs
Pull Force, Case 2: 16.85 lbs
Surface Field: 6510 Gauss
Max Operating Temp: 176ºF (80ºC)
Brmax: 13,200 Gauss
BHmax: 42 MGOe

The D8X8 is a great sized adult cylinder magnet. One fits comfortably in the hand of most adults, which makes them excellent stud or metal detectors. This size is great for picking up loose metal objects. This cylinder is also a great size for science demonstrations and magic tricks.

	Pull Force, Case 1 vs. distance: Magnet to a Steel Plate.
	Pull Force, Case 2 vs. distance: Between 2 Steel Plates.
	Pull Force, Case 3 vs. distance: Magnet to Magnet.
	Pull Force, Case 4 vs. distance: Magnet to Magnet Repulsion.
	Click this link for a depiction of the magnetic field.
	View B-H curves for this magnet.

	Click this link to download a PDF Specification Sheet.
	Click this link to download a PDF drawing of this product.
	Click this link to download a Certificate of Compliance for this product.
	Click this link to download a RoHS Statement of Compliance for this product.
	Click this link to download a Material Safety Data Sheet (MSDS) for this product.
	Click this link to download a Conflict Minerals Reporting Template (CMRT).
	Click this link to download a Certificate of Origin for this product.
	Click this link for a REACH compliance statement.
	Click this link to download a .STEP file (3D model).
	Click this link to download an .IGS file (3D model).
