B22C - Neodymium Block Magnet

Description
Technical
Downloads

Dimensions: 1/8" x 1/8" x 3/4" thick
Tolerances: ±0.004" x ±0.004" x ±0.004"
Material: NdFeB, Grade N42
Plating/Coating: Ni-Cu-Ni (Nickel)
Magnetization Direction: Thru Thickness
Weight: 0.051 oz. (1.44 g)
Pull Force, Case 1: 1.22 lbs
Pull Force, Case 2: 1.22 lbs
Surface Field: 6571 Gauss
Max Operating Temp: 176ºF (80ºC)
Brmax: 13,200 Gauss
BHmax: 42 MGOe

These small blocks are magnetized through the 3/4" thickness. The poles are located on the small 1/8" x 1/8" faces. Easy to grab, but still provides a strong hold.

This long magnetization direction can be a great choice for use with reed switches.

	Pull Force, Case 1 vs. distance: Magnet to a Steel Plate.
	Pull Force, Case 2 vs. distance: Between 2 Steel Plates.
	Pull Force, Case 3 vs. distance: Magnet to Magnet.
	Pull Force, Case 4 vs. distance: Magnet to Magnet Repulsion.
	Click here for a depiction of the magnetic field.
	View B-H curves for this magnet.

	Click here to download a PDF Specification Sheet.
	Click here to download a PDF drawing of this product.
	Click here to download a Certificate of Compliance for this product.
	Click here to download a RoHS Statement of Compliance for this product.
	Click here to download a Material Safety Data Sheet (MSDS) for this product.
	Click here to download a Conflict Minerals Reporting Template (CMRT).
	Click here to download a Certificate of Origin for this product.
	Click here for a REACH compliance statement.
	Click here to download a .STEP file (3D model).
	Click here to download an .IGS file (3D model).

Download the free Adobe Acrobat Reader

Price: $0.74

Quantity:

Qty:

Price ea.	Qty
$0.74	1-24
$0.72	25-49
$0.71	50-99
$0.69	100-249
$0.67	250-499
$0.66	500-999
$0.64	1000-2499
$0.62	2500-4999
$0.61	5000-9999
$0.59	10000-24999
For pricing at higher order quantities, please email us!
