- Dimensions:
D=75mm (2.95")
H=70mm (2.76")
M=10mm (0.39") (M10 Coarse threaded hook) - Material: NdFeB, Grade N38
- Plating/Coating: Ni-Cu-Ni (Nickel)
- Magnetization Direction: Axial (Poles on Flat Ends)
- Weight: 34.74 oz
- Pull Force: 500 lbs
- Surface Field: N/A
- Brmax: 12,600 Gauss
- BHmax: 38 MGOe
