D43 - Neodymium Disc Magnet - 1/4" Dia x 3/16" Thi

• Dimensions: 1/4" dia. x 3/16" thick
• Tolerances: ±0.004" x ±0.004"
• Material: NdFeB, Grade N42
• Plating/Coating: Ni-Cu-Ni (Nickel)
• Magnetization Direction: Axial (Poles on Flat Ends)
• Weight: 0.0399 oz. (1.13 g)
• Pull Force, Case 1: 3.00 lbs
• Pull Force, Case 2: 3.78 lbs
• Surface Field: 5492 Gauss
• Max Operating Temp: 176ºF (80ºC)
• Brmax: 13,200 Gauss
• BHmax: 42 MGOe

This disc is the incredibly popular 1/4" diameter in a new thickness! It is a very solid and strong neodymium disc magnet.
