D72 - Neodymium Disc Magnet - 7/16" Dia x 1/8" Thi

• Dimensions: 7/16" dia. x 1/8" thick
• Tolerances: ±0.004" x ±0.004"
• Material: NdFeB, Grade N42
• Plating/Coating: Ni-Cu-Ni (Nickel)
• Magnetization Direction: Axial (Poles on Flat Ends)
• Weight: 0.0815 oz. (2.31 g)
• Pull Force, Case 1: 5.43 lbs
• Pull Force, Case 2: 12.55 lbs
• Surface Field: 3275 Gauss
• Max Operating Temp: 176ºF (80ºC)
• Brmax: 13,200 Gauss
• BHmax: 42 MGOe

This is another very difficult to find size. These discs are strong, sturdy, and useful for many applications.

This size is also available in grade N52 as part number D72-N52.
