> DE1 - Neodymium Disc Magnet

DE1 - Neodymium Disc Magnet

de1-neodymium-disc-magnet

de1-neodymium-disc-magnet--thumbnail-1

de1-neodymium-disc-magnet--thumbnail-2

$1.62

-

+

Buy more, Save more!

Quantity based discounts

Price ea.	Qty	Discount
$1.62	1-9
$1.58	10-24	2%
$1.55	25-49	4%
$1.51	50-99	7%
$1.48	100-249	9%
$1.44	250-499	11%
$1.41	500-999	13%
$1.37	1000-2499	15%
$1.34	2500-4999	17%
$1.30	5000-9999	20%
Email us for even bigger discounts on higher order quantities

Description
Technical
Downloads

Magnetization direction

Dimensions: 7/8" dia. x 1/16" thick
Tolerances: ±0.004" x ±0.004"
Material: NdFeB, Grade N42
Plating/Coating: Ni-Cu-Ni (Nickel)
Magnetization Direction: Axial (Poles on Flat Ends)
Weight: 0.163 oz. (4.62 g)
Pull Force, Case 1: 5.50 lbs
Pull Force, Case 2: 43.50 lbs
Surface Field: 933 Gauss
Max Operating Temp: 176ºF (80ºC)
Brmax: 13,200 Gauss
BHmax: 42 MGOe

This is another difficult-to-find size. These thin discs have a great strength-to-size ratio. They are useful wherever you need a thin disc with a lot of holding power.
