DX0C-N52 - Neodymium Disc Magnet

$20.88

Buy more, Save more!

Quantity based discounts

Price ea.	Qty	Discount
$20.88	1
$20.42	2	2%
$19.95	3-4	4%
$19.49	5-9	7%
$19.02	10-24	9%
$18.56	25-49	11%
$18.09	50-99	13%
$17.63	100-249	16%
$17.16	250-499	18%
$16.70	500-999	20%
Email us for even bigger discounts on higher order quantities

Description
Technical
Downloads
Video

Dimensions: 1" dia. x 3/4" thick
Tolerances: ±0.004" x ±0.004"
Material: NdFeB, Grade N52
Plating/Coating: Ni-Cu-Ni (Nickel)
Magnetization Direction: Axial (Poles on Flat Ends)
Weight: 2.55 oz. (72.4 g)
Pull Force, Case 1: 68.47 lbs
Pull Force, Case 2: 75.40 lbs
Surface Field: 6157 Gauss
Max Operating Temp: 176ºF (80ºC)
Brmax: 14,800 Gauss
BHmax: 52 MGOe

These stout discs are incredibly powerful and should only be handled by people experienced with the power of neodymium magnets. The DX0C-N52 is very strong and must be handled with caution. Don't let the small stature of this disc fool you, the DX0C-N52 is a monster and can pinch very hard.

	Pull Force, Case 1 vs. distance: Magnet to a Steel Plate.
	Pull Force, Case 2 vs. distance: Between 2 Steel Plates.
	Pull Force, Case 3 vs. distance: Magnet to Magnet.
	Pull Force, Case 4 vs. distance: Magnet to Magnet Repulsion.
	Click this link for a depiction of the magnetic field.
	View B-H curves for this magnet.

	Click this link to download a PDF Specification Sheet.
	Click this link to download a PDF drawing of this product.
	Click this link to download a Certificate of Compliance for this product.
	Click this link to download a RoHS Statement of Compliance for this product.
	Click this link to download a Material Safety Data Sheet (MSDS) for this product.
	Click this link to download a Conflict Minerals Reporting Template (CMRT).
	Click this link to download a Certificate of Origin for this product.
	Click this link for a REACH compliance statement.
	Click this link to download a .STEP file (3D model).
	Click this link to download an .IGS file (3D model).
